Key Features & Benefits:
? ATEX, UL and CSA Approvals
? Withstands EN/IEC 60079-0 impact test
? Enhanced H 2 S and silicone poison resistance
Performance Characteristics
MEASUREMENT | |
Operating Principle | Catalytic Oxidation |
Gases Detected | Combustible gases |
Suitable for | Methane, ethane, propane, butane, pentane, hexane, carbon monoxide & hydrogen |
Unsuitable for | Higher hydrocarbons, alcohols, ketones, esters, hydrogen sulfide and other sulfur containing compounds |
Range | 0-100% LEL |
Sensitivity | 24 ± 4 mV/%methane |
T90 Response Time Poison Resistance
| <20 seconds (methane) Resistance to H 2 S poisoning Superior silicone resistance |
ELECTRICAL | |
Operating Voltage | 3.0 VDC |
Detector Operating Current | 75 ± 7 mA
|
Maximum Power Consumption | 263 mW
|
Resolution | Electronics dependant |
MECHANICAL | |
Casing Material | Stainless steel 316 |
Pin Material | Gold plated brass |
Weight | 24 g (nominal) |
Orientation Sensitivity | None |
ENVIRONMENTAL | |
Operating Temperature Range | -20 oC to +55 oC
|
Operating Pressure Range | 1 atm ± 20%
|
Operating Humidity Range | 0-90% RH non-condensing
|
LIFETIME | |
Long Term Span DriftLong Term Zero Drift | <5% signal/month <5% LEL methane /month
|
Recommended Storage Temp | 0 oC to 20oC
|
Shelf life | 6 months in sealed container |
Warranty
| 12 months from date of despatch |
Relative Sensitivity
The table below shows the variation in response of the CiTipeL on exposure to a range of gases and vapours atthe same %LEL concentration. The figures are experimentally derived and expressed relative to the methanesignal (=100). Testing was performed using 50%LEL CH 4 (based on 100%LEL CH 4 = 5%vol.)
Note: The results are intended for guidance only. For the most accurate measurements, an instrument should be calibrated using the gas under investigation.
Gas / Vapour | Relative Sensitivity* | Gas / Vapour
| Relative Sensitivity* |
Methane | 100 | Carbon monoxide | 120 |
Propane | 65 | Hydrogen | 110 |
n-Butane | 65 | Ammonia ** | 140 |
n-Pentane | 55 | Cyclohexane | 50 |
n-Hexane | 50 | Ethylene | 95 |
Acetylene | 90 | 1, 3-Butadiene | 60 |
* Each sensitivity has been rounded to the nearest 5%** T 90 for ammonia has been extended. Contact City Technology for further details. | |||
